Steel Shot is exceptionally durable due to its low friability, the impact of blasting actually further tempers the shot so that its hardness increases over time, allowing the media to deliver consistent, repeatable performance over thousands of cycles. Steel Shot is used to for heavy scouring and to produce very bright finishes.
Cast steel angular grit produced by crushing specially heat treated
steel shot Its behaviour in service depends on hardness-a characteristic
readily modified by suitable heat treatment.
Steel Grit is used mainly in wheel last machines for cleaning or
preparation work on special surfaces.
In addition, GL and GH Steel Grit are equally suitable for use in
wheelblast machines and in most cases air blast equipment.
| Products | Steel Grit | |
|---|---|---|
| Chemical Composition | C | 0.80~1.20% |
| Mn | 0.35~1.20% | |
| Si | ≥0.40 | |
| S | ≤0.05% | |
| P | ≤0.05% | |
| Microhardness | GP:42-52 HRC GL:53-60 HRC GH:60-64 HRC |
|
| Hardness Deviation | Max Deviation ±3.0HRC | |
| Microstructure | Tempered Martensite or Sorbite | |
| Density | 7.6 g/cm³ |
G10, G12, G14, G16, G18, G25, G40, G50, G80, G120
| SAE | Application |
|---|---|
| G-12 G-14 G-16 |
Blasting/descaling medium-to-large cast steel, cast
iron, forged
pieces,steel plate and rubber adhered work pieces. |
|
G-18
G-25 G-40 |
Cutting/grinding stone; Blasting rubber adhered work
pieces;
Descaling steel plate, container, ship hall before painting; Cleaning small-to-medium cast steel, cast iron, forged pieces, etc. |
| G-50 G-80 G-120 |
Blasting/descaling steel wire, spanner, steel pipe
before painting
process; Cleaning precision castings (eg. golf blocks). |
| Products | Steel Shot | |
|---|---|---|
| Chemical Composition | C | 0.80% (m/m) to 1.2% (m/m) |
| Mn | 0.35% (m/m) to 1.2% (m/m) | |
| Si | min. 0.4% (m/m) | |
| S | max. 0.05% (m/m) | |
| P | max. 0.05% (m/m) | |
| Microhardness | Normal:40~50HRC (377~509HV) | |
| Hardness Deviation | Max Deviation ±3.0HRC | |
| Microstructure | Tempered Martensite or Sorbite | |
| Density | 7.2 g/cm³ |
Used for blast cleaning of casting, die-casting, forging, sand removal of casting, steel plate, H type steel, steel structure.
Rust removal of casting, forging, steel plate, H type steel, steel structure, descaling of forging.
Shot peening of gear, heat treatment.
Shot blasting of profile steel, ship board, steel board, steel material, steel structure.
Pre-treatment of surface, steel board, profile steel, steel structure, before-painting.
